Description:
Access level: public
Reference: SDOC-498608282-1371
Download: PDF
sensolus SENSE T 4000 BLE Temperature Sensor www.sensolus.com | info@sensolus.com Small puck-sized BLE temperature sensor designed for precise temperature monitoring across a wide range. With its compact form factor and extended battery life, it's ideal for various temperature-sensitive applications. Bluetooth Low Energy Up to 7 years battery life IP68 rated Ø 57mm × 20mm (2¼ in × ²⁵⁄₃₂ in) 41g (1.45 oz) Temperature Monitoring Temperature Range -40°C to +85°C (-40°F to 185°F) Accuracy ±0.5°C (±0.8°F) Operating Temperature -40°C to +85°C Connectivity Technology Bluetooth Low Energy (BLE) Transmission Range Up to 60 meters (65 yards) Advertisement Period 2 seconds at +4dBm Physical Characteristics Dimensions Ø 57mm × 20mm (2¼ in × ²⁵⁄₃₂ in) Weight 41 grams (1.45 oz) Casing Material DELRIN (POM C) - Food Grade (90/128/EEC) IP Rating IP68 Mounting Double-sided tape Power Battery Type Non-replaceable internal lithium battery (3 VDC) Battery Life Up to 7 years (depending on transmission power)sensolus SENSE T 4000 BLE Temperature Sensor www.sensolus.com | info@sensolus.com Certifications Europe • EN 300 328 • EN 301 489 • EN 55032 • EN 62368-1 • CE marked USA • FCC 15.247 • FCC PT 15B Canada • ISED RSS-247 • ICES-003 Environmental RoHS compliant
Description:
Access level: public
Reference: SDOC-498608282-1385
Download: PDF
Installation manual for SENSE T 4000 www.sensolus.com | info@sensolus.com February 2025 Mounting the sensor All mounting options for your sensor can be found in the Sensolus product mounting instructions. Sensor orientation The SENSE T 4000 has a detection range of 4 meters. Setup in cooler trailers There are three recommended installation locations for cooler trailers: Option Location Notes Option 1 Back wall Install the sensor on the back wall of the cooling truck. Option 2 Ceiling Install the sensor on the ceiling of the cooling truck. Make sure the sensor does not get damaged during (un)loading. Option 3 Back door Install the sensor on the back door of the truck.
