Description:
Access level: public
Reference: SDOC-498608282-1372
Download: PDF
sensolus SENSE T 4004 BLE Temperature Sensor with Probe www.sensolus.com | info@sensolus.com Compact BLE temperature sensor with external PT1000 probe for precise temperature monitoring across an extended range. Ideal for applications requiring remote temperature measurement with food-grade materials and extended battery life. Bluetooth Low Energy Up to 7 years battery life IP68 probe / IP65 housing Ø 57mm × 20mm (2¼ in × ²⁵⁄₃₂ in) 63g (2.2 oz) Temperature Monitoring Probe Range -80°C to +200°C Accuracy • ±0.5°C typical (-30°C to +60°C) • ±2°C typical (-80°C to +200°C) Resolution 0.1°C Housing Operating Temperature -40°C to +85°C Probe Specifications Sensor Type PT1000 Connection M8 x 1.0 Dimensions Ø 3mm × 28mm Cable Length 1 meter Material • Stainless steel probe • Teflon cable insulation IP Rating IP68 Connectivity Technology Bluetooth Low Energy (BLE) Transmission Range Up to 60 meters (65 yards) Advertisement Period 2 seconds at +4dBm Physical Characteristics Housing Dimensions Ø 57mm × 20mm (2¼ in × ²⁵⁄₃₂ in) Weight 63 grams (2.2 oz) Casing Material DELRIN (POM C) - Food Grade Housing IP Rating IP65sensolus SENSE T 4004 BLE Temperature Sensor with Probe www.sensolus.com | info@sensolus.com Power Battery Type Non-replaceable internal lithium battery (3 VDC) Battery Life Up to 7 years (depending on transmission power) Certifications Europe • EN 300 328 • EN 301 489 • EN 55032 • EN 62368-1 • EN 12830 • CE marked USA FCC certified Canada ISED certified UK UKCA certified Environmental RoHS compliant
Description:
Access level: public
Reference: SDOC-498608282-1386
Download: PDF
Installation manual for SENSE T 4004 www.sensolus.com | info@sensolus.com February 2025 Mounting the sensor All mounting options for your sensor can be found in the Sensolus product mounting instructions. Mounting the probe This is a lab product. The optimal mounting instruction for the probe is still being investigated. At this moment there are no standardized instructions to mount the probe since this is use case specific. Testing the sensor before actual usage is required. Mounting advice for liquid containers You will need quality thermal paste to mount the probe onto the liquid container.Installation manual for SENSE T 4004 www.sensolus.com | info@sensolus.com February 2025 Step Action Details Locate the thermal stud Find the stud on the liquids container There is a stud with external thread on the liquids container. Loosen the nut. The thermal probe of the SENSE T 4004 should be attached onto the stud. Mount the probe Apply thermal paste and attach Apply enough thermal paste onto the sensor probe and attach to the stud. Screw the nut back onto the stud. Make sure everything is fastened tightly together. Mount the sensor Position the sensor correctly Mount the sensor in the tank shell, with the probe behind the insulation and the sensor as close as possible to the external cover to ensure BLE connection to a tracker. Fit outer insulation, making sure the pocket is well insulated. Do not use too much insulation. Close up everything. Locate the thermal studInstallation manual for SENSE T 4004 www.sensolus.com | info@sensolus.com February 2025 Mount the probe with thermal paste Mount the sensor
