Description:
Access level: public
Reference: SDOC-498608282-90
Download: PDF
www.sensolus.com | info@sensolus.com Tap on the edit icon ( ). You can now edit the name, tags and picture of the tag. Save the setting by tapping the save icon ( ). Activation and installation manual for TAG 2002 Activation of the TAG 2002 Download and install the Sensolus app from the Apple or Android store. Log in to the app with your Sensolus credentials. Adjust the settings of the Bluetooth tag tracker Click on the search bar. Click on the barcode icon next to the search bar. The camera of your phone will open. Scan the Barcode printed on the front of the BLE tracker. Click on your tracker that will appear in your screen to go to settings.www.sensolus.com | info@sensolus.com Installing with double sided tape Cleaning the surfaces Clean the area on the asset where you want to add the tag and also the back side of the tag to get rid of any grease/ oil. Sand both surfaces lightly for a few seconds to increase surface area. Clean it again to remove the dust. Installing the Tag 2002 Add the double sided adhesive tape to the tag. Push the tracker into place and push on the tracker's top to ensure it is mounted properly.
Description: TAG 2002 spec sheet EN
Access level: public
Reference: SDOC-498608282-130
Download: PDF
June 25, 2025 9:54 AM www.sensolus.com | info@sensolus.com TAG 2002 TAG 2002 is a rugged location tag tracker built for reliable, long-term asset tracking in harsh environments. Using Bluetooth Low Energy (BLE) technology, it enables the localization of assets when in range of Sensolus devices with smart BLE gateway capabilities. Up to 10 years of battery life IP69K BLE iBeacon advertising IP69K Water & dust resistance Size Ø 57 mm base – Thickness : 20 mm Weight 41 gram Color White Casing DELRIN (POM C) Compatible with food products (90/128/EEC) -40°C to +85°C Operating temperature Battery · Up to 10 years battery life, actual battery life may be reduced by extreme temperatures. · Non replaceable 3 VDC – Internal lithium battery Connectivity Transmission power Strong emission power (+4dBm) enables detection at ranges of 50m or more. Actual detection range is strongly influenced by physical environment. Mechanics & design Mounting Certificates CE: EN 300 328/ EN 301 489 & EN 55032 / EN 62368-1 Europe FCC: 15.247 / FCC PT 15B USA ISED: RSS-247 / ICES-003 Canada Yes RoHS 20 mm 57 mm 57 mm Instructions for mounting the device are available in the Sensolus documentation center.
Description:
Access level: public
Reference: SDOC-498608282-1408
Download: PDF
sensolus TAG 2002 BLE Location Tag Tracker www.sensolus.com | info@sensolus.com Rugged location tag tracker built for reliable, long-term asset tracking in harsh environments. Using Bluetooth Low Energy (BLE) technology, it enables the localization of assets when in range of Sensolus devices with smart BLE gateway capabilities. BLE iBeacon advertising Up to 10 years battery life IP69K rated Ø 57mm × 20mm 41g Connectivity Technology Bluetooth Low Energy (BLE) iBeacon Transmission Range 50 meters or more at +4dBm emission power. Actual detection range is strongly influenced by physical environment. Mechanics & Design Dimensions Ø 57mm base, 20mm thickness Weight 41 grams Color White Casing Material DELRIN (POM C) - Compatible with food products (90/128/EEC) Water & Dust Resistance IP69K Operating Temperature -40°C to +85°C Power Battery Type Non-replaceable internal lithium battery (3 VDC) Battery Life Up to 10 years. Actual battery life may be reduced by extreme temperatures. Certifications Europe CE: EN 300 328 / EN 301 489 & EN 55032 / EN 62368-1 USA FCC: 15.247 / FCC PT 15B Canada ISED: RSS-247 / ICES-003 Environmental RoHS compliant
Description:
Access level: public
Reference: SDOC-498608282-1524
Download: PDF
sensolus TAG 2002 Traceur de tag de localisation BLE www.sensolus.com | info@sensolus.com Traceur de tag de localisation robuste conçu pour le suivi fiable et à long terme d'actifs dans des environnements difficiles. Grâce à la technologie Bluetooth Low Energy (BLE), il permet la localisation des actifs lorsqu'ils sont à portée des appareils Sensolus dotés de fonctionnalités de passerelle BLE intelligente. Publicité BLE iBeacon Jusqu'à 10 ans d'autonomie Certifié IP69K Ø 57mm × 20mm 41g Connectivité Technologie Bluetooth Low Energy (BLE) iBeacon Portée de transmission 50 mètres ou plus à une puissance d'émission de +4 dBm. La portée de détection réelle est fortement influencée par l'environnement physique. Mécanique & Design Dimensions Ø 57 mm de base, 20 mm d'épaisseur Poids 41 grammes Couleur Blanc Matériau du boîtier DELRIN (POM C) - Compatible avec les produits alimentaires (90/128/CEE) Résistance à l'eau et à la poussière IP69K Température de fonctionnement -40°C à +85°C Alimentation Type de batterie Batterie lithium interne non remplaçable (3 VDC) Durée de vie de la batterie Jusqu'à 10 ans. La durée de vie réelle de la batterie peut être réduite par des températures extrêmes. Certifications Europe CE: EN 300 328 / EN 301 489 & EN 55032 / EN 62368-1 États-Unis FCC: 15.247 / FCC PT 15B Canada ISED: RSS-247 / ICES-003 Environnement Conforme RoHS
Description:
Access level: public
Reference: SDOC-498608282-1523
Download: PDF
sensolus TAG 2002 BLE-Standort-Tag-Tracker www.sensolus.com | info@sensolus.com Robuster Standort-Tag-Tracker für zuverlässiges, langfristiges Asset-Tracking in rauen Umgebungen. Mithilfe der Bluetooth Low Energy (BLE)-Technologie ermöglicht er die Lokalisierung von Assets, wenn sie sich in Reichweite von Sensolus-Geräten mit intelligenten BLE-Gateway-Funktionen befinden. BLE-iBeacon-Werbung Bis zu 10 Jahre Batterielaufzeit IP69K-zertifiziert Ø 57mm × 20mm 41g Konnektivität Technologie Bluetooth Low Energy (BLE) iBeacon Übertragungsreichweite 50 Meter oder mehr bei +4 dBm Sendeleistung. Die tatsächliche Erkennungsreichweite wird stark von der physischen Umgebung beeinflusst. Mechanik & Design Abmessungen Ø 57 mm Basis, 20 mm Dicke Gewicht 41 Gramm Farbe Weiß Gehäusematerial DELRIN (POM C) - Lebensmittelkonform (90/128/EWG) Wasser- und Staubschutz IP69K Betriebstemperatur -40°C bis +85°C Stromversorgung Batterietyp Nicht austauschbare interne Lithiumbatterie (3 VDC) Batterielaufzeit Bis zu 10 Jahre. Die tatsächliche Batterielaufzeit kann durch extreme Temperaturen verkürzt werden. Zertifizierungen Europa CE: EN 300 328 / EN 301 489 & EN 55032 / EN 62368-1 USA FCC: 15.247 / FCC PT 15B Kanada ISED: RSS-247 / ICES-003 Umwelt RoHS-konform
Description:
Access level: public
Reference: SDOC-498608282-1525
Download: PDF
sensolus TAG 2002 BLE locatie-tag tracker www.sensolus.com | info@sensolus.com Robuuste locatie-tag tracker voor betrouwbare, langdurige asset tracking in zware omgevingen. Met Bluetooth Low Energy (BLE)-technologie maakt hij de lokalisatie van assets mogelijk wanneer ze zich binnen bereik bevinden van Sensolus-apparaten met slimme BLE-gateway-mogelijkheden. BLE iBeacon-advertentie Tot 10 jaar batterijlevensduur IP69K-gecertificeerd Ø 57mm × 20mm 41g Connectiviteit Technologie Bluetooth Low Energy (BLE) iBeacon Transmissiebereik 50 meter of meer bij +4 dBm zendvermogen. Het daadwerkelijke detectiebereik wordt sterk beïnvloed door de fysieke omgeving. Mechanica & Design Afmetingen Ø 57 mm basis, 20 mm dikte Gewicht 41 gram Kleur Wit Behuizingsmateriaal DELRIN (POM C) - Geschikt voor contact met levensmiddelen (90/128/EEG) Water- en stofweerstand IP69K Bedrijfstemperatuur -40°C tot +85°C Voeding Batterijtype Niet-vervangbare interne lithiumbatterij (3 VDC) Batterijlevensduur Tot 10 jaar. De daadwerkelijke batterijlevensduur kan worden verkort door extreme temperaturen. Certificeringen Europa CE: EN 300 328 / EN 301 489 & EN 55032 / EN 62368-1 VS FCC: 15.247 / FCC PT 15B Canada ISED: RSS-247 / ICES-003 Milieu RoHS-conform
Description:
Access level: public
Reference: SDOC-498608282-1544
Download: PDF
sensolus TAG 2002 Tracker de etiqueta de localización BLE www.sensolus.com | info@sensolus.com Robusto tracker de etiqueta de localización diseñado para el seguimiento de activos fiable y a largo plazo en entornos adversos. Mediante la tecnología Bluetooth Low Energy (BLE), permite la localización de activos cuando se encuentran en el rango de dispositivos Sensolus con capacidades inteligentes de gateway BLE. Publicidad BLE iBeacon Hasta 10 años de vida útil de la batería Certificado IP69K Ø 57mm × 20mm 41g Conectividad Tecnología Bluetooth Low Energy (BLE) iBeacon Alcance de transmisión 50 metros o más a una potencia de emisión de +4 dBm. El alcance de detección real se ve fuertemente influenciado por el entorno físico. Mecánica y diseño Dimensiones Ø 57 mm de base, 20 mm de grosor Peso 41 gramos Color Blanco Material de la carcasa DELRIN (POM C) - Compatible con productos alimentarios (90/128/CEE) Resistencia al agua y al polvo IP69K Temperatura de funcionamiento -40°C a +85°C Fuente de alimentación Tipo de batería Batería de litio interna no reemplazable (3 VDC) Vida útil de la batería Hasta 10 años. La vida útil real de la batería puede verse reducida por temperaturas extremas. Certificaciones Europa CE: EN 300 328 / EN 301 489 & EN 55032 / EN 62368-1 EE. UU. FCC: 15.247 / FCC PT 15B Canadá ISED: RSS-247 / ICES-003 Ambiental Cumple con RoHS
For installation instructions, see Installation instructions.
