Description:
Access level: public
Reference: SDOC-498608282-1388
Download: PDF
Installation and activation manual TAG 2001 www.sensolus.com | info@sensolus.com October 30, 2024 Activation The TAG 2001 is already activated when you receive it. No activation steps are required. Verify activation To verify if the tag is activated, perform the following steps in a dark environment: 1 Open the tag by removing the cover. → 2 Press the small button inside the tag. → 3 A blue LED will light up, confirming the tag is activated. 4 Close the tag again by replacing the cover. Mounting the TAG 2001 Guidelines for mounting the tracker can be found in the Sensolus Documentation center. Mounting with screws, rivets, or bolts The TAG 2001 has mounting holes for affixing with rivets, screws, or bolts. The spacing between the mounting holes is 49mm.Installation and activation manual TAG 2001 www.sensolus.com | info@sensolus.com October 30, 2024 Important mounting warning Do not install the TAG 2001 close to magnets. Magnets can interfere with the tag's operation. Edit tag information with the mobile app The Sensolus mobile app allows you to edit the name, tags, and picture of a TAG 2001. Download the Sensolus mobile app from the App Store or Google Play. Open the Sensolus smartphone app and login with your credentials. Go to the tag you want to edit via the asset list, map, or search function. In the search function, use the QR code scanner to open the tag details page. Tap on the edit icon. You can now edit the name, tags, and picture of the tag. Save the settings byInstallation and activation manual TAG 2001 www.sensolus.com | info@sensolus.com October 30, 2024 tapping the save icon.
Description: TAG 2001 spec sheet EN
Access level: public
Reference: SDOC-498608282-129
Download: PDF
June 25, 2025 10:10 AM www.sensolus.com | info@sensolus.com TAG 2001-REV2 40,5 mm 17,6 mm IP67 Water & dust resistance Size 40,5 x 58 x 17.6 mm Weight 22 gram Color White Casing ABS plastic -20°C to +60°C Operating temperature Battery · Up to 10 years battery life, actual battery life may be reduced by extreme temperatures. · User replaceable CR2477Xbatteries Connectivity Mechanics & design Certifications · CE · FCC Mounting Instructions for mounting the device are available in the Sensolus documentation center. · Bluetooth QDID/EPL 58 mm TAG 2001 is a rugged location tag tracker built for reliable, long-term asset tracking in harsh environments. Using Bluetooth Low Energy (BLE) technology, it enables the localization of assets when in range of Sensolus devices with smart BLE gateway capabilities. Up to 10 years of battery life IP67 BLE iBeacon advertising Transmission range Strong emission power (+4dBm) enables detection at ranges of 50m or more. Actual detection range is strongly influenced by physical environment.
Description: 3D-file of the TAG 2001 in STP format
Access level: end-user
Reference: SDOC-498608282-688
Download: STP
Description:
Access level: public
Reference: SDOC-498608282-1520
Download: PDF
sensolus TAG 2001 BLE-Standort-Tag-Tracker www.sensolus.com | info@sensolus.com Robuster Standort-Tag-Tracker für zuverlässiges, langfristiges Asset-Tracking in rauen Umgebungen. Mithilfe der Bluetooth Low Energy (BLE)-Technologie ermöglicht er die Lokalisierung von Assets, wenn sie sich in Reichweite von Sensolus-Geräten mit intelligenten BLE-Gateway-Funktionen befinden. BLE-iBeacon-Werbung Bis zu 10 Jahre Batterielaufzeit IP67-zertifiziert 40.5 × 58 × 17.6mm 22g Konnektivität Technologie Bluetooth Low Energy (BLE) iBeacon Übertragungsreichweite 50 Meter oder mehr bei +4 dBm Sendeleistung. Die tatsächliche Erkennungsreichweite wird stark von der physischen Umgebung beeinflusst. Mechanik & Design Abmessungen 40.5 × 58 × 17.6mm Gewicht 22 Gramm Farbe Weiß Gehäusematerial ABS-Kunststoff Wasser- und Staubschutz IP67 Betriebstemperatur -20°C bis +60°C Stromversorgung Batterietyp Vom Benutzer austauschbare CR2477X-Batterien Batterielaufzeit Bis zu 10 Jahre. Die tatsächliche Batterielaufzeit kann durch extreme Temperaturen verkürzt werden. Zertifizierungen Regulatorisch • CE • FCC • Bluetooth QDID/EPL
Description:
Access level: public
Reference: SDOC-498608282-1521
Download: PDF
sensolus TAG 2001 Traceur de tag de localisation BLE www.sensolus.com | info@sensolus.com Traceur de tag de localisation robuste conçu pour le suivi fiable et à long terme d'actifs dans des environnements difficiles. Grâce à la technologie Bluetooth Low Energy (BLE), il permet la localisation des actifs lorsqu'ils sont à portée des appareils Sensolus dotés de fonctionnalités de passerelle BLE intelligente. Publicité BLE iBeacon Jusqu'à 10 ans d'autonomie Certifié IP67 40.5 × 58 × 17.6mm 22g Connectivité Technologie Bluetooth Low Energy (BLE) iBeacon Portée de transmission 50 mètres ou plus à une puissance d'émission de +4 dBm. La portée de détection réelle est fortement influencée par l'environnement physique. Mécanique & Design Dimensions 40.5 × 58 × 17.6mm Poids 22 grammes Couleur Blanc Matériau du boîtier Plastique ABS Résistance à l'eau et à la poussière IP67 Température de fonctionnement -20°C à +60°C Alimentation Type de batterie Piles CR2477X remplaçables par l'utilisateur Durée de vie de la batterie Jusqu'à 10 ans. La durée de vie réelle de la batterie peut être réduite par des températures extrêmes. Certifications Réglementaire • CE • FCC • Bluetooth QDID/EPL
Description:
Access level: public
Reference: SDOC-498608282-1522
Download: PDF
sensolus TAG 2001 BLE locatie-tag tracker www.sensolus.com | info@sensolus.com Robuuste locatie-tag tracker voor betrouwbare, langdurige asset tracking in zware omgevingen. Met Bluetooth Low Energy (BLE)-technologie maakt hij de lokalisatie van assets mogelijk wanneer ze zich binnen bereik bevinden van Sensolus-apparaten met slimme BLE-gateway-mogelijkheden. BLE iBeacon-advertentie Tot 10 jaar batterijlevensduur IP67-gecertificeerd 40.5 × 58 × 17.6mm 22g Connectiviteit Technologie Bluetooth Low Energy (BLE) iBeacon Transmissiebereik 50 meter of meer bij +4 dBm zendvermogen. Het daadwerkelijke detectiebereik wordt sterk beïnvloed door de fysieke omgeving. Mechanica & Design Afmetingen 40.5 × 58 × 17.6mm Gewicht 22 gram Kleur Wit Behuizingsmateriaal ABS-kunststof Water- en stofweerstand IP67 Bedrijfstemperatuur -20°C tot +60°C Voeding Batterijtype Door gebruiker vervangbare CR2477X-batterijen Batterijlevensduur Tot 10 jaar. De daadwerkelijke batterijlevensduur kan worden verkort door extreme temperaturen. Certificeringen Regelgevend • CE • FCC • Bluetooth QDID/EPL
Description:
Access level: public
Reference: SDOC-498608282-1407
Download: PDF
sensolus TAG 2001 BLE Location Tag Tracker www.sensolus.com | info@sensolus.com Rugged location tag tracker built for reliable, long-term asset tracking in harsh environments. Using Bluetooth Low Energy (BLE) technology, it enables the localization of assets when in range of Sensolus devices with smart BLE gateway capabilities. BLE iBeacon advertising Up to 10 years battery life IP67 rated 40.5 × 58 × 17.6mm 22g Connectivity Technology Bluetooth Low Energy (BLE) iBeacon Transmission Range 50 meters or more at +4dBm emission power. Actual detection range is strongly influenced by physical environment. Mechanics & Design Dimensions 40.5 × 58 × 17.6mm Weight 22 grams Color White Casing Material ABS plastic Water & Dust Resistance IP67 Operating Temperature -20°C to +60°C Power Battery Type User replaceable CR2477X batteries Battery Life Up to 10 years. Actual battery life may be reduced by extreme temperatures. Certifications Regulatory • CE • FCC • Bluetooth QDID/EPL
Description:
Access level: public
Reference: SDOC-498608282-1454
Download: PDF
Installations- und Aktivierungshandbuch TAG 2001 www.sensolus.com | info@sensolus.com October 30, 2024 Aktivierung Der TAG 2001 ist bereits aktiviert, wenn Sie ihn erhalten. Es sind keine Aktivierungsschritte erforderlich. Aktivierung überprüfen Um zu überprüfen, ob der Tag aktiviert ist, führen Sie die folgenden Schritte in einer dunklen Umgebung durch: 1 Öffnen Sie den Tag, indem Sie die Abdeckung entfernen. → 2 Drücken Sie den kleinen Knopf im Inneren des Tags. → 3 Eine blaue LED leuchtet auf und bestätigt, dass der Tag aktiviert ist. 4 Schließen Sie den Tag wieder, indem Sie die Abdeckung aufsetzen. Montage des TAG 2001 Richtlinien zur Montage des Trackers finden Sie im Sensolus Dokumentationszentrum. Montage mit Schrauben, Nieten oder Bolzen Der TAG 2001 verfügt über Montagelöcher zur Befestigung mit Nieten, Schrauben oder Bolzen. Der Abstand zwischen den Montagelöchern beträgt 49 mm.Installations- und Aktivierungshandbuch TAG 2001 www.sensolus.com | info@sensolus.com October 30, 2024 Wichtiger Montagehinweis Installieren Sie den TAG 2001 nicht in der Nähe von Magneten. Magnete können den Betrieb des Tags beeinträchtigen. Tag-Informationen mit der mobilen App bearbeiten Die Sensolus-App ermöglicht es Ihnen, den Namen, die Tags und das Bild eines TAG 2001 zu bearbeiten. Laden Sie die Sensolus-App aus dem App Store oder Google Play herunter. Öffnen Sie die Sensolus-Smartphone-App und melden Sie sich mit Ihren Anmeldedaten an. Navigieren Sie zu dem Tag, den Sie bearbeiten möchten, über die Asset-Liste, die Karte oder die Suchfunktion. Verwenden SieInstallations- und Aktivierungshandbuch TAG 2001 www.sensolus.com | info@sensolus.com October 30, 2024 in der Suchfunktion den QR-Code-Scanner, um die Tag-Detailseite zu öffnen. Tippen Sie auf das Bearbeitungssymbol. Sie können nun den Namen, die Tags und das Bild des Tags bearbeiten. Speichern Sie die Einstellungen, indem Sie auf das Speichersymbol tippen.
Description:
Access level: public
Reference: SDOC-498608282-1455
Download: PDF
Manuel d'installation et d'activation TAG 2001 www.sensolus.com | info@sensolus.com October 30, 2024 Activation Le TAG 2001 est déjà activé lorsque vous le recevez. Aucune étape d'activation n'est requise. Vérifier l'activation Pour vérifier si le tag est activé, effectuez les étapes suivantes dans un environnement sombre : 1 Ouvrez le tag en retirant le couvercle. → 2 Appuyez sur le petit bouton à l'intérieur du tag. → 3 Une LED bleue s'allume, confirmant que le tag est activé. 4 Refermez le tag en remettant le couvercle en place. Montage du TAG 2001 Les directives de montage du tracker sont disponibles dans le centre de documentation Sensolus. Montage avec des vis, des rivets ou des boulons Le TAG 2001 dispose de trous de montage pour la fixation avec des rivets, des vis ou des boulons. L'écartement entre les trous de montage est de 49 mm.Manuel d'installation et d'activation TAG 2001 www.sensolus.com | info@sensolus.com October 30, 2024 Avertissement de montage important Ne pas installer le TAG 2001 à proximité d'aimants. Les aimants peuvent interférer avec le fonctionnement du tag. Modifier les informations du tag avec l'application mobile L'application mobile Sensolus permet de modifier le nom, les tags et la photo d'un TAG 2001. Téléchargez l'application mobile Sensolus depuis l'App Store ou Google Play.Manuel d'installation et d'activation TAG 2001 www.sensolus.com | info@sensolus.com October 30, 2024 Ouvrez l'application Sensolus sur votre smartphone et connectez-vous avec vos identifiants. Accédez au tag à modifier via la liste des actifs, la carte ou la fonction de recherche. Dans la fonction de recherche, utilisez le scanner de code QR pour ouvrir la page de détails du tag. Appuyez sur l'icône de modification. Vous pouvez maintenant modifier le nom, les tags et la photo du tag. Enregistrez les paramètres en appuyant sur l'icône de sauvegarde.
Description:
Access level: public
Reference: SDOC-498608282-1456
Download: PDF
Installatie- en activatiehandleiding TAG 2001 www.sensolus.com | info@sensolus.com October 30, 2024 Activatie De TAG 2001 is al geactiveerd wanneer u hem ontvangt. Er zijn geen activatiestappen vereist. Activatie verifiëren Om te controleren of de tag geactiveerd is, voert u de volgende stappen uit in een donkere omgeving: 1 Open de tag door de afdekking te verwijderen. → 2 Druk op de kleine knop aan de binnenkant van de tag. → 3 Een blauwe LED gaat branden, wat bevestigt dat de tag geactiveerd is. 4 Sluit de tag weer door de afdekking terug te plaatsen. Montage van de TAG 2001 Richtlijnen voor de montage van de tracker zijn te vinden in het Sensolus Documentatiecentrum. Montage met schroeven, klinknagels of bouten De TAG 2001 heeft montagegaten voor bevestiging met klinknagels, schroeven of bouten. De afstand tussen de montagegaten is 49 mm.Installatie- en activatiehandleiding TAG 2001 www.sensolus.com | info@sensolus.com October 30, 2024 Belangrijke montagewaarschuwing Installeer de TAG 2001 niet in de buurt van magneten. Magneten kunnen de werking van de tag verstoren. Tag-informatie bewerken met de mobiele app Met de Sensolus-app kunt u de naam, tags en foto van een TAG 2001 bewerken. Download de Sensolus-app via de App Store of Google Play. Open de Sensolus-smartphone-app en meld u aan met uw inloggegevens. Ga naar de tag die u wilt bewerken via de assetlijst, de kaart of de zoekfunctie. Gebruik in de zoekfunctie de QR-codescanner om de tagdetailpagina te openen. Tik op het bewerkingspictogram. U kunt nu de naam, tags en foto van de tagInstallatie- en activatiehandleiding TAG 2001 www.sensolus.com | info@sensolus.com October 30, 2024 bewerken. Sla de instellingen op door op het opslagpictogram te tikken.
Description:
Access level: public
Reference: SDOC-498608282-1543
Download: PDF
sensolus TAG 2001 Tracker de etiqueta de ubicación BLE www.sensolus.com | info@sensolus.com Tracker de etiqueta de ubicación robusto diseñado para el seguimiento de activos fiable y a largo plazo en entornos adversos. Mediante la tecnología Bluetooth Low Energy (BLE), permite la localización de activos cuando se encuentran en el rango de dispositivos Sensolus con capacidades inteligentes de gateway BLE. Publicidad BLE iBeacon Hasta 10 años de vida útil de la batería Certificación IP67 40.5 × 58 × 17.6mm 22g Conectividad Tecnología Bluetooth Low Energy (BLE) iBeacon Alcance de transmisión 50 metros o más a una potencia de emisión de +4 dBm. El alcance de detección real está fuertemente influenciado por el entorno físico. Mecánica y diseño Dimensiones 40.5 × 58 × 17.6mm Peso 22 gramos Color Blanco Material de la carcasa Plástico ABS Resistencia al agua y al polvo IP67 Temperatura de funcionamiento -20°C a +60°C Alimentación Tipo de batería Baterías CR2477X reemplazables por el usuario Vida útil de la batería Hasta 10 años. La vida útil real de la batería puede reducirse en condiciones de temperaturas extremas. Certificaciones Regulatorio • CE • FCC • Bluetooth QDID/EPL
For installation instructions, see Installation instructions. Earlier revision:
Description: TAG 2001 REV 1 spec sheet EN
Access level: partner
Reference: SDOC-498608282-882
Download: PDF
January 22, 2024 11:07 AM www.sensolus.com | info@sensolus.com BLE tag standard TAG 2001-REV1 BLuetooth 5.0 compatible Range up to 60 meter Up to 7 years of battery life IP67 40,5 mm 17,6 mm The standard low-cost BLE tag. IP67 Water & dust resistance Size 40,5 x 58 x 17.6 mm Weight 22 gram Color Black Casing ABS plastic -20°C to +70°C (Battery limit) Operating temperature Battery · Up to 7 years of battery life depending on transmission power · User replaceable CR2477 batteries Connectivity Transmission power Up to 60 meter. BLE advertisement period 4 seconds at + 4dBm Mechanics & design Certifications · CE · FCC Mounting · Double sided tape · Screws · No not mount close to magnets · Bluetooth QDID/EPL 58 mm
